Cisco Catalyst WS-C3750X-48T-S: Specs, Features & Price in Pakistan

Not every network edge requires Power over Ethernet. In fact, modern data center racks often rely on dedicated power feeds for endpoints. Therefore, paying for massive PoE budgets adds unnecessary expense. The Cisco Catalyst WS-C3750X-48T-S solves this challenge directly. Specifically, Cisco designed this switch for high-density Gigabit data access and Layer 3 routing. For Pakistani enterprise IT teams, the 3750-X series delivers reliable switching without thermal overhead.

Architectural Advantages of the Catalyst 3750-X Data Switch

The WS-C3750X-48T-S runs the Cisco IP Base software image. Consequently, it delivers essential enterprise Layer 3 capabilities right out of the box. Network administrators can configure static routing, RIP, EIGRP stub, and basic OSPF routes effortlessly.

Furthermore, the switch features Cisco StackWise Plus technology. This architecture allows engineers to interconnect up to nine switches into a single logical unit. As a result, the stack delivers 64 Gbps of dedicated stacking throughput. Moreover, centralized management eliminates traffic bottlenecks during peak corporate operations.

Technical Specifications (WS-C3750X-48T-S)

You should review hardware specifications before mounting equipment in your rack. In particular, the WS-C3750X-48T-S provides specific throughput and modular features:

• Port Density: 48 x 10/100/1000 Gigabit Ethernet data ports.

• PoE Capability: Non-PoE (The “T” denotes data-only connectivity).

• Uplink Modules: Requires optional C3KX-NM network modules (1G SFP or 10G SFP+).

• Power Supply: Standard 350W AC power supply (C3KX-PWR-350WAC).

• Redundancy: Dual hot-swappable power supply bays.

• Feature Set: IP Base Layer 3 software.

• Switching Capacity: 160 Gbps forwarding bandwidth.

• Form Factor: 1 RU rack-mountable metal chassis.

High-Density Non-PoE Switching and Modular Power

Standard PoE switches generate substantial heat and consume extra electricity. In contrast, the WS-C3750X-48T-S powers data-only endpoints efficiently. Because the switch does not carry PoE loads, it operates using a modest 350W power supply. This significantly reduces overall utility costs and rack thermal output.

However, network reliability remains uncompromised. The chassis supports dual redundant power supplies for complete electrical failover. In addition, engineers can deploy Cisco StackPower technology across the stack. StackPower pools individual power supplies into a shared resource. Therefore, if one power unit drops offline, other supplies instantly sustain the switch. This prevents sudden switch reboots and costly corporate network downtime.

Ideal Deployment Scenarios in Pakistani Corporate Networks

Our enterprise engineering team at Trade Orient Pakistan recommends this switch for three primary deployments:

1. Top-of-Rack Server Aggregation: First, the 48 Gigabit ports connect Dell PowerEdge and HPE ProLiant rack servers reliably.

2. High-Density Workstation Switching: Second, corporate office floors need dedicated data connections for desktop PCs and printers.

3. Campus Core Distribution: Finally, adding optional 10G uplink modules allows this switch to aggregate downstream access switches cleanly.

Frequently Asked Questions

Does the Cisco WS-C3750X-48T-S provide PoE or PoE+?
No, this switch does not provide PoE power. The “T” in the part number indicates data-only ports. Therefore, you must select the WS-C3750X-48P-S if your access points require PoE+.

What uplink ports come with this switch out of the box?
The base switch chassis does not include fixed uplinks. Instead, it features an empty modular uplink slot. You must install an optional network module such as the C3KX-NM-1G or C3KX-NM-10G.

Is the WS-C3750X-48T-S a Layer 2 or Layer 3 switch?
This switch is a fully functional Layer 3 device. Because it runs the IP Base image, it performs inter-VLAN routing and basic static routing easily.

Procure Tested Cisco Hardware with Trade Orient Pakistan

Deploying enterprise switching requires a reliable hardware partner. Since 2008, Trade Orient Pakistan has supplied verified enterprise networking equipment across Pakistan. Our network engineers test every switch thoroughly before dispatch. Specifically, we inspect all 48 ports, test power supplies, and verify internal cooling fans.

Furthermore, we clear legacy configurations and update system firmware safely. We also support corporate clients with structured Annual Maintenance Contracts (AMC) and SLA-backed maintenance. As a result, your IT team secures dependable hardware alongside local engineering support.

Contact our Karachi technical team today to request stock availability and B2B pricing.
